Design System

A design system is a collection of reusable components, defined by clear standards, that can be assembled together to build any number of applications.

RealtimeKit's UI kit uses the Atomic design principle, which logically organizes screens for various devices, making it a versatile system. Design tokens are used in RealtimeKit's UI Kit to maintain a consistent look across platforms. By combining design tokens and Atomic design principles, RealtimeKit ensures a smooth and adaptable user interface experience on different platforms.

Design Tokens

Design tokens are the single source of truth to name and store design decisions.They are values that help keep the design consistent and flexible. These values include things like font styles, spacing, colors, borders, and more, allowing you to easily customize the overall look and feel of a system.

In the Flutter UI kit, design tokens are shared and managed using themes. Themes in Flutter use the ThemeData class to store and propagate design properties, such as colors, fonts, and more, throughout the widget tree.

Let's understand how you can customize your UI with RealtimeKit's Flutter UI Kit using design tokens.

Customize themes with design tokens

RealtimeKit offers the RtkDesignToken class to customize the theme of the UI kit. Pass the RtkDesignToken object within the RtkUIKitInfo object to customize the theme.

With RtkDesignToken, you can customize the following design properties:

• backgroundColor:The background color of the UI Kit.
• textOnBackground: The text color on the background of the UI Kit.
• backgroundColorSwatch: The background color swatch of the UI Kit.
• brandColor: The primary color of the UI Kit.
• textOnBrand: The text color on the brand color of the UI Kit.
• brandColorSwatch: The brand color swatch of the UI Kit.
• danger: The danger color of the UI Kit.
• success: The success color of the UI Kit.
• warning: The warning color of the UI Kit.

You have two options to customize the UI Kit's theme:

Pass a single color.

You can pass a single color to the backgroundColor, brandColor parameters. Or you can use a combination of backgroundColorSwatch and brandColor to customize the theme.

Use a color swatch.

For the brand color swatch, make sure it contains 5 entries with keys 300, 400, 500, 600, and 700. For the background color swatch, provide 5 entries with keys 600, 700, 800, 900, and 1000.

To achieve this, utilize the RtkColorSwatch class with two parameters: the default color key and a map of colors.

final primarySwatch = RtkColorSwatch(
    500,
    {
      300: Colors.blue.shade300,
      400: Colors.blue.shade400,
      500: Colors.blue.shade500,
      600: Colors.blue.shade600,
      700: Colors.blue.shade700,
    },
  );

Customize borders with configuration

To customize the border radius and border width of the UI Kit, you can use the RtkBorderRadius and RtkBorderWidth enum values in the design token.

Here are the available RtkBorderRadius values:

Token Name	values
RtkBorderRadius	sharp, rounded, extraRounded, circular

Here are the available RtkBorderWidth values:

Token Name	values
RtkBorderWidth	none, thin, fat

Example

Here's an example of how you can customize the Flutter UI Kit using the design token:

final uikitInfo = RtkUIKitInfo(meetingInfo,
    designToken: RtkDesignToken(
      colorToken: RtkColorToken(
          borderRadius: RtkBorderRadius.circular,
          borderWidth: RtkBorderWidth.fat,
          backgroundColor: Colors.black,
          textOnBrand: Colors.white,
          textOnBackground: Colors.white,
          danger: Colors.red,
          success: Colors.green,
          warning: Colors.yellow,
          brandColorSwatch: RtkColorSwatch(
            500,
            {
              300: Colors.blue.shade300,
              400: Colors.blue.shade400,
              500: Colors.blue.shade500,
              600: Colors.blue.shade600,
              700: Colors.blue.shade700,
            },
          )),
    ));
